Skid-mounted Filling Station For CO2
Skid-mounted Filling Station For CO2
The CO2 cylinder filling skid produced by Zoiun is a pumping system designed for filling CO2 cylinders. Comprising a CO2 cryogenic pump, a control system, pressure interlocks, and multiple filling scales, the system operates fully automatically.
Its workflow utilizes a "front-and-rear dual-scale group" mode for automatic switching: once one side is fully filled, the system automatically closes that side's filling valve and simultaneously opens the valve on the other side to begin filling, ensuring continuous operation.

Skid Features
The system features an innovative "Dual-Station Automatic Switching" operation mode. By configuring the front and rear filling stations as a paired group, it achieves continuous operation:
- Automatic Start/Stop: Once the cylinder on one side reaches the preset weight, the system automatically closes that side's filling valve.
- Seamless Switching: Simultaneously, the filling valve on the other side automatically opens to immediately begin a new filling cycle.
- Efficiency Improvement: This alternating mechanism eliminates manual intervention and waiting time, significantly enhancing filling efficiency and production continuity.
Specifications
| Design Temperature | -196 °C |
| Max Work Pressure | 80 bar |
| Fluid | LCO2 |
| Flow Rate | 600-1200L/H |
| Cylinder Suitable | 40L, 50L |
| Skid Size |
L5000*W2100*H2100 (mm) |
| Cylinder Quantity |
6 scales |
